Product Description:
Double Sphere Flexible Rubber Jointconsists of outer rubber, inner rubber, framework layer, and reinforcing bar and flange. Relying on rubber’s special performances as long range elasticity, air impermeability, medium, climate and radiation resistance, rubber expansion couplings can reduce the vibration and noise of pipeline, and can be caused by the temperature change of heat bilges cold shrink compensation effect.
Features:
Allow for four way movements.
Precision molded of synthetic rubber and nylon.
Execllent ability to absorb vibration and noise.
Withstand high pressure.6.Easy to install,use floating flange.
Technical Parameters:
Diameter
DN |
Length
mm |
Axis displacement |
Radial
displacement |
Deflexion
displacement |
| TYPE 1 |
TYPE 2 |
| mm |
inch |
Extension |
Compression |
Extension |
Comgression |
TYPE 1 |
TYPE 2 |
TYPE1 |
TYPF 2 |
| 32 |
11/4" |
165 |
30 |
50 |
|
|
45 |
|
±7.5° |
|
| 40 |
11/2” |
165 |
30 |
50 |
|
|
45 |
|
±7.5° |
|
| 50 |
2" |
165 |
30 |
50 |
|
|
45 |
|
±7.5° |
|
| 65 |
21/2” |
175 |
30 |
50 |
|
|
45 |
|
±7.5° |
|
| 80 |
3" |
175 |
30 |
50 |
|
|
45 |
|
±7.5° |
|
| 100 |
4" |
225 |
35 |
50 |
|
|
45 |
|
±7.5° |
|
| 125 |
5" |
225 |
35 |
50 |
|
|
45 |
|
±7.5° |
|
| 150 |
6" |
225 |
35 |
50 |
|
|
45 |
|
±7.5° |
|
| 200 |
8" |
325 |
35 |
60 |
|
|
|
|
|
|
| 250 |
10" |
325 |
35 |
60 |
|
|
|
|
|
|
| 300 |
12" |
325 |
35 |
60 |
|
|
|
|
|
|
| 350 |
14" |
325 |
35 |
60 |
|
|
|
|
|
|
| 400 |
16" |
400 |
40 |
60 |
|
|
|
|
|
|
| 450 |
18" |
400 |
|
|
65 |
70 |
|
70 |
|
±12° |
| 500 |
20" |
400 |
|
|
65 |
70 |
|
70 |
|
±12° |
| 600 |
24" |
400 |
|
|
70 |
75 |
|
75 |
|
±12° |
| 700 |
28" |
400 |
|
|
70 |
75 |
|
75 |
|
±12° |
| 800 |
32" |
450 |
|
|
70 |
75 |
|
75 |
|
±12° |
| 900 |
36" |
450 |
|
|
70 |
75 |
|
75 |
|
±12° |
| 1000 |
40" |
450 |
|
|
75 |
80 |
|
70 |
|
±12° |
| 1200 |
48" |
500 |
|
|
75 |
80 |
|
70 |
|
±10° |
| 1400 |
56" |
500 |
|
|
75 |
80 |
|
70 |
|
±10° |
| 1600 |
64" |
500 |
|
|
75 |
80 |
|
70 |
|
±10° |
| 1800 |
72" |
500 |
|
|
80 |
85 |
|
65 |
|
±10° |
| 2000 |
80" |
550 |
|
|
80 |
85 |
|
65 |
|
±10° |
| 2200 |
88" |
550 |
|
|
80 |
85 |
|
65 |
|
±10° |
| 2400 |
96" |
550 |
|
|
80 |
85 |
|
65 |
|
±10° |
| 2600 |
104" |
550 |
|
|
80 |
85 |
|
65 |
|
±10° |
| 2800 |
112" |
550 |
|
|
80 |
85 |
|
65 |
|
±10° |
| 3000 |
120" |
550 |
|
|
80 |
85 |
|
65 |
|
±10 |
| • Special size and length can be customized for you. |
Application characteristics:
Wide applicability: Double ball rubber joints are widely used in various pipeline systems, especially in conveying pipeline systems for media with temperatures ≤ 120 degrees, including seawater, fresh water, hot and cold water, domestic sewage, etc.
Special purpose: Especially used for rapid installation and maintenance of pumps and valves, as well as for insulation and heat resistance of water pipeline joints and cooling tower circulating water pipelines in non corrosive environments of chemical and petroleum equipment.
Support and Services:
- Delivery inspection (pressure test, specification test, material, quantity, packing).
- The quality is guaranteed for 12 months, supportthird-party testing.
- Free solutions and drawings can be provided.
- A well-trained and disciplined professional packaging team.
- 24h online service, quick response before and after sales.
- Support online factory inspection
- On-time delivery
- Free samples can be provided
FAQ:
Q1: What is the model number range for the liwei Double sphere flexible rubber joint?
A1: The model number range for the liwei Double sphere flexible rubber joint is from DN15 to DN4000, accommodating a wide variety of pipeline diameters.
Q2: Where is the liwei Double sphere flexible rubber joint manufactured?
A2: The liwei Double sphere flexible rubber joint is manufactured in Henan, China, ensuring high-quality standards and manufacturing excellence.
Q3: What certifications does the liwei Double sphere flexible rubber joint have?
A3: The liwei Double sphere flexible rubber joint holds numerous certifications including ISO9001, TUV, WRAS, CO, MTC, PL, IV, etc., which attest to its quality and compliance with international standards.
Q4: What are the packaging details for the liwei Double sphere flexible rubber joint?
A4: The liwei Double sphere flexible rubber joint is packaged with inner plastic film and an outer wooden case. For multiple compensators packed in one case, a steel frame is used to ensure stability and prevent damage during transportation.
